Canon EOS 6D MIC Port and Remote Socket Replacement Tutorial

Is your Canon EOS 6D’s MIC port or remote socket damaged? Don’t worry, Salvation Repair has got you covered In this tutorial, we’ll guide you through the process of replacing these essential components. Please note that this repair requires some technical expertise and patience, but with our step-by-step instructions, you’ll be able to fix your camera in no time.

Step 1: Remove the Viewfinder Cover

Start by removing the viewfinder cover by pinching the sides and sliding it upward. This will give you access to the camera’s internal components.

Step 2: Open the Battery Door

Next, open the battery door on the bottom of the camera. Use your thumb to slide the small black tab on the inside of the battery door up and pull the door off the camera.

battery door”>

Step 3: Remove the Rubber Covering

Slide your fingernail or the flat end of the spudger underneath the rubber covering and gently peel it off all sides of the camera.

Step 4: Open the HDMI/AV/MIC Port Covers

Open the covers to the HDMI/AV/MIC ports on the side of the camera by gently pulling outward on the bottom of the covers. Rotate the covers to the side so that you can see the connection ports inside.

Step 5: Remove the Screws

Remove the following screws:

• Two silver 5mm Phillips #00
• One black 6mm Phillips #00

These screws hold the MIC port and remote socket in place.

Step 6: Remove the MIC Port and Remote Socket

Use the flat end of the spudger to gently lift up on the right side of the MIC port. Grip the sides of the port with your fingers and gently wiggle it up and down while pulling outward to remove it.

Step 7: Reassemble the Camera

Once you’ve replaced the MIC port and remote socket, reassemble the camera in the reverse order that you disassembled it. Make sure all screws are securely tightened.

Conclusion

Replacing the MIC port and remote socket on your Canon EOS 6D requires some technical expertise, but with this tutorial, you should be able to fix your camera with ease. If you’re not comfortable with DIY repairs or if you’re not sure about any of the steps, consider scheduling a repair with Salvation Repair at https://salvationrepair.com/repair. We offer a limited lifetime guarantee on all parts and labor.
