DIY VTech Kidizoom Smartwatch DX2 Replacement Guide

Duration: 45 minutes

Steps: 7 Steps

First things first, let’s get that main board out of the way! To remove the screen or battery, you’ll need to take out the main board first. Follow our clear and easy-to-read guide to get started.

Step 1

VTech Kidizoom Smartwatch DX2 Motherboard Replacement

– Start by turning the watch over so that its back is facing up.

Step 2

– Alright, grab your Phillips #00 screwdriver and unscrew the four 6.0 mm screws chilling in each corner of the watch. Once they’re out, gently pop off the backplate. Easy peasy!

Tools Used

Phillips #00 Screwdriver

Step 3

– Lift that backplate up with a gentle touch to pop it off.

Step 4

– Once you’ve popped off the backplate, gently lift the master switch up from the circuit board.

Step 5

– Grab a Phillips #00 screwdriver and gently unscrew the 0.6 mm screw. Easy peasy!

Tools Used

Phillips #00 Screwdriver

Step 6

– Gently lift the speaker out of the case—keep it cool and connected to the motherboard.

Step 7

– Time to put everything back together—just reverse the steps you followed to take it apart. Easy as pie!

– Not feeling it? No biggie. If you need help, you can always schedule a repair.

– High five for tackling this repair yourself!

Tools Used

Tweezers
