How to Replace ASUS D550MA DVD Drive Tutorial

Duration: 45 minutes
Steps: 7 Steps

Is your DVD drive refusing to play your go-to flicks? It might be time for a little upgrade! This guide will help you smoothly remove your DVD drive and get back to movie night in no time.

Step 1

– Grab your trusty Philips #1 screwdriver and let’s tackle those nine screws on the back cover!

Step 2

– Flip your laptop over and pop that display open like a pro!

– Slide the flat edge of your trusty spudger into the groove of the keyboard cover.

– With the spudger in place, gently nudge the casing apart by gliding it along the edge. You’ve got this!

Tools Used
  1. Spudger

Step 3

– Gently lift the cover from the front of the laptop, but don’t worry about taking it off completely just yet.

– Keep an eye on where those three white and blue data cables are connecting the keyboard to the laptop’s main board. You’ll want to remember their spots!

Step 4

– Unplug the three data cables from the motherboard. You’ve got this!

Tools Used
  1. Spudger

Step 5

– Gently detach the keyboard module from the laptop, ensuring it’s fully disconnected. You’re on your way to a smoother repair journey!

Step 6

– Grab your trusty Phillips #1 Screwdriver and gently unscrew the lone screw keeping that drive snug as a bug!

Step 7

– To disconnect the drive from the motherboard, simply slide it out to the right side of the laptop.
