How to Replace Samsung Galaxy Tab A 10.1 Headphone Jack
Duration: 45 minutes
Steps: 10 Steps
Having trouble getting your audio to play? Don’t worry, we’ve got you covered! If the sound isn’t working even after trying out some troubleshooting tips, it’s probably time to swap out that headphone jack. Luckily, our step-by-step guide is here to walk you through it. If you need help, you can always schedule a repair.
Step 1
If your plastic opening tool isn’t cutting it, try a metal spudger—it might just do the trick! Heads up, though, it could leave some scuffs on the plastic parts of your device.
Oh, and don’t forget to pop out the micro SD card (if your device has one) before diving in. Save yourself a headache later!
– Set the device down with the front facing you—think of it as saying, ‘Hey there!’
– Kick off near one of those smooth, curvy edges (photo two will show you the vibe).
– Slide a trusty plastic opening tool between the front and back panels like slicing through a sandwich. Easy does it!
Step 2
When you lift off the back panel, expect a satisfying click sound—it’s the device letting you know it’s ready for the next step!
– Once you’ve slipped that trusty plastic opening tool in there, give it a little wiggle around the edges to help those panels part ways.
– Now, gently lift off the back panel and reveal the inner workings of your device!
Step 3
– Peel off that pesky adhesive film and pop up the retaining flap on the ZIF battery connector like a pro!
– Gently slide the orange battery ribbon cable out of the ZIF connector, and you’re one step closer to giving your device a new life!
Step 5
– Pop up that retaining tab like a pro and gently slide out the black LCD ribbon—smooth moves!
Step 6
Be super careful when handling the battery – it’s the big rectangular white and black piece, and you’ll want to avoid puncturing it to keep things safe and successful!
– Grab your trusty Phillips #000 screwdriver and unscrew those ten 4 mm screws holding the battery in place. They’re tiny, so keep ’em safe!
– Slip a plastic opening tool under the bottom edge of the battery, near the speakers. Gently lift it up and let the battery break free like it’s ready for a new adventure!
Tools Used
Step 7
– Pop up those two ZIF connectors on the motherboard using the plastic opening tool.
– Gently slide the orange ribbon cables out of the ZIF connectors.
– Take out the front-facing camera.
Step 8
– Unplug the headphone jack from the motherboard.
– Grab a Phillips #000 screwdriver and remove six 4mm screws.
Step 9
Watch out for those sneaky connectors!
– Gently slide the plastic opening tool beneath the motherboard and lift it out of the tablet with care.
– Take off the metal bracket that was hiding under the charging port and set it aside for safekeeping.
Step 10
– Let’s get started! Use a Phillips #000 screwdriver to remove two of the 4mm screws around the headphone jack – easy peasy!
– Gently lift the metal piece covering the headphone jack from one side. Take your time, you got this!
– Now it’s time to free the headphone jack! Carefully lift it out, and you’ll be one step closer to a fully functional device. If you need help, you can always schedule a repair
Success!
