Jot® Plastic 8-Digit Pocket Calculator Teardown
Duration: 45 minutes
Steps: 4 Steps
How Everything Works -LSI Think of the LSI as the calculator’s brain—it handles all the math magic. -Keyboard Membrane The keyboard membrane acts like a gatekeeper, stopping energy from the power circuit and sending signals to the LSI when you press a key. -Lithium Battery The lithium battery keeps the calculator running by powering the circuit, so you don’t have to worry about it shutting off in the middle of your calculations. -The resistor The resistor acts as a speed bump for the circuit, slowing things down just enough to help the battery last longer.
Step 1
– Grab your screwdriver and carefully unscrew those tiny screws holding everything together. You’ve got this—step by step, you’ll have that device open in no time. If you need a hand, remember you can always schedule a repair.
Step 2
– Launch your calculator app and get ready for the next step.
Step 3
– Take out the keyboard sensors and gently lift away the display.
Step 4
– Lift out the keyboard membrane and set it aside—you’re doing great!
